Curved Florence 2 Column 500mm
Made to order
Every radiator is built to the size your room needs. Choose sections, finish and valves in the builder, or let the finder suggest a model for your space.
CUR-F2C-502
Specifications
| Ref | Attribute | Value |
|---|---|---|
| A | Height with legs | 602mm |
| B | Pipe centre to floor | 134mm |
| C | Max section depth | 67mm |
| D | Interaxis distance | 435mm |
| E | Height without legs | 502mm |
| F | Mid section depth | 65mm |
| G | Pipe centre to wall (Atlas bracket) | 63mm |
| L | Section length | 45mm |
| – | Internal volume per section | 0.6L |
| – | Leg section weight | 1kg |
| – | Mid section weight | 0.7kg |
| – | Max single-piece delivery size | 25sections |
| – | Output at ΔT30 | 19.4W |
| – | Output at ΔT50 | 36.7W |
φ = Km × ΔTn · Km = 0.271 · n = 1.255
Tested to EN 442 · Politecnico di Milano · Test ref: ENE/MRT.RES.01003_A
Declaration of Performance: 202009-1016 · CE marked
Available sizes
Outputs in watts per radiator, at the stated temperature difference.
| SKU | Sections | Length (mm) | ΔT50 (W) | ΔT30 (W) | Delivered in | Signature | Branded Paints |
|---|---|---|---|---|---|---|---|
| CUR-F2C-502-03 | 3 | 165 | 110 | 58 | One piece | — | — |
| CUR-F2C-502-04 | 4 | 210 | 147 | 77 | One piece | — | — |
| CUR-F2C-502-05 | 5 | 255 | 184 | 97 | One piece | — | — |
| CUR-F2C-502-06 | 6 | 300 | 220 | 116 | One piece | — | — |
| CUR-F2C-502-07 | 7 | 345 | 257 | 135 | One piece | — | — |
| CUR-F2C-502-08 | 8 | 390 | 294 | 155 | One piece | — | — |
| CUR-F2C-502-09 | 9 | 435 | 331 | 174 | One piece | — | — |
| CUR-F2C-502-10 | 10 | 480 | 367 | 194 | One piece | — | — |
| CUR-F2C-502-11 | 11 | 525 | 404 | 213 | One piece | — | — |
| CUR-F2C-502-12 | 12 | 570 | 441 | 232 | One piece | — | — |
| CUR-F2C-502-13 | 13 | 615 | 478 | 252 | One piece | — | — |
| CUR-F2C-502-14 | 14 | 660 | 514 | 271 | One piece | — | — |
| CUR-F2C-502-15 | 15 | 705 | 551 | 290 | One piece | — | — |
| CUR-F2C-502-16 | 16 | 750 | 588 | 310 | One piece | — | — |
| CUR-F2C-502-17 | 17 | 795 | 625 | 329 | One piece | — | — |
| CUR-F2C-502-18 | 18 | 840 | 661 | 348 | One piece | — | — |
| CUR-F2C-502-19 | 19 | 885 | 698 | 368 | One piece | — | — |
| CUR-F2C-502-20 | 20 | 930 | 735 | 387 | One piece | — | — |
| CUR-F2C-502-21 | 21 | 975 | 772 | 406 | One piece | — | — |
| CUR-F2C-502-22 | 22 | 1020 | 808 | 426 | One piece | — | — |
| CUR-F2C-502-23 | 23 | 1065 | 845 | 445 | One piece | — | — |
| CUR-F2C-502-24 | 24 | 1110 | 882 | 464 | One piece | — | — |
| CUR-F2C-502-25 | 25 | 1155 | 919 | 484 | One piece | — | — |
| CUR-F2C-502-26 | 26 | 1200 | 955 | 503 | 2 pieces | — | — |
| CUR-F2C-502-27 | 27 | 1245 | 992 | 523 | 2 pieces | — | — |
| CUR-F2C-502-28 | 28 | 1290 | 1029 | 542 | 2 pieces | — | — |
| CUR-F2C-502-29 | 29 | 1335 | 1066 | 561 | 2 pieces | — | — |
| CUR-F2C-502-30 | 30 | 1380 | 1102 | 581 | 2 pieces | — | — |
| CUR-F2C-502-31 | 31 | 1425 | 1139 | 600 | 2 pieces | — | — |
| CUR-F2C-502-32 | 32 | 1470 | 1176 | 619 | 2 pieces | — | — |
| CUR-F2C-502-33 | 33 | 1515 | 1213 | 639 | 2 pieces | — | — |
| CUR-F2C-502-34 | 34 | 1560 | 1249 | 658 | 2 pieces | — | — |
| CUR-F2C-502-35 | 35 | 1605 | 1286 | 677 | 2 pieces | — | — |
| CUR-F2C-502-36 | 36 | 1650 | 1323 | 697 | 2 pieces | — | — |
| CUR-F2C-502-37 | 37 | 1695 | 1359 | 716 | 2 pieces | — | — |
| CUR-F2C-502-38 | 38 | 1740 | 1396 | 735 | 2 pieces | — | — |
| CUR-F2C-502-39 | 39 | 1785 | 1433 | 755 | 2 pieces | — | — |
| CUR-F2C-502-40 | 40 | 1830 | 1470 | 774 | 2 pieces | — | — |
Branded Paints: Little Greene, Farrow & Ball, Paint & Paper Library, Mylands
Heat output
Output varies with flow temperature. The curve shows watts per section across the usual range of ΔT.
| ΔT (K) | Output per section (W) |
|---|---|
| ΔT15 | 8.1 |
| ΔT20 | 11.6 |
| ΔT25 | 15.4 |
| ΔT30 | 19.4 |
| ΔT35 | 23.5 |
| ΔT40 | 27.8 |
| ΔT45 | 32.2 |
| ΔT50 | 36.7 |
