Emmeline II 670mm
Made to order
Every radiator is built to the size your room needs. Choose sections, finish and valves in the builder, or let the finder suggest a model for your space.
CI-EML2-670
Available sizes
Outputs in watts per radiator, at the stated temperature difference.
| SKU | Sections | Length (mm) | ΔT50 (W) | ΔT30 (W) | Delivered in | Signature | Branded Paints | Bare Metal |
|---|---|---|---|---|---|---|---|---|
| CI-EML2-670-03 | 3 | 230 | 261 | 137 | One piece | — | — | — |
| CI-EML2-670-04 | 4 | 296 | 348 | 182 | One piece | — | — | — |
| CI-EML2-670-05 | 5 | 363 | 435 | 228 | One piece | — | — | — |
| CI-EML2-670-06 | 6 | 429 | 522 | 273 | One piece | — | — | — |
| CI-EML2-670-07 | 7 | 496 | 609 | 319 | One piece | — | — | — |
| CI-EML2-670-08 | 8 | 562 | 695 | 365 | One piece | — | — | — |
| CI-EML2-670-09 | 9 | 629 | 782 | 410 | One piece | — | — | — |
| CI-EML2-670-10 | 10 | 695 | 869 | 456 | One piece | — | — | — |
| CI-EML2-670-11 | 11 | 762 | 956 | 501 | One piece | — | — | — |
| CI-EML2-670-12 | 12 | 828 | 1043 | 547 | One piece | — | — | — |
| CI-EML2-670-13 | 13 | 895 | 1130 | 593 | One piece | — | — | — |
| CI-EML2-670-14 | 14 | 961 | 1217 | 638 | One piece | — | — | — |
| CI-EML2-670-15 | 15 | 1028 | 1304 | 684 | 2 pieces | — | — | — |
| CI-EML2-670-16 | 16 | 1094 | 1391 | 729 | 2 pieces | — | — | — |
| CI-EML2-670-17 | 17 | 1161 | 1478 | 775 | 2 pieces | — | — | — |
| CI-EML2-670-18 | 18 | 1227 | 1565 | 820 | 2 pieces | — | — | — |
| CI-EML2-670-19 | 19 | 1294 | 1652 | 866 | 2 pieces | — | — | — |
| CI-EML2-670-20 | 20 | 1360 | 1739 | 912 | 2 pieces | — | — | — |
| CI-EML2-670-21 | 21 | 1427 | 1826 | 957 | 2 pieces | — | — | — |
| CI-EML2-670-22 | 22 | 1493 | 1913 | 1003 | 2 pieces | — | — | — |
| CI-EML2-670-23 | 23 | 1560 | 1999 | 1048 | 2 pieces | — | — | — |
| CI-EML2-670-24 | 24 | 1626 | 2086 | 1094 | 2 pieces | — | — | — |
| CI-EML2-670-25 | 25 | 1693 | 2173 | 1139 | 2 pieces | — | — | — |
| CI-EML2-670-26 | 26 | 1759 | 2260 | 1185 | 2 pieces | — | — | — |
| CI-EML2-670-27 | 27 | 1826 | 2347 | 1231 | 2 pieces | — | — | — |
| CI-EML2-670-28 | 28 | 1892 | 2434 | 1276 | 2 pieces | — | — | — |
| CI-EML2-670-29 | 29 | 1959 | 2521 | 1322 | 3 pieces | — | — | — |
| CI-EML2-670-30 | 30 | 2025 | 2608 | 1367 | 3 pieces | — | — | — |
| CI-EML2-670-31 | 31 | 2092 | 2695 | 1413 | 3 pieces | — | — | — |
| CI-EML2-670-32 | 32 | 2158 | 2782 | 1459 | 3 pieces | — | — | — |
| CI-EML2-670-33 | 33 | 2225 | 2869 | 1504 | 3 pieces | — | — | — |
| CI-EML2-670-34 | 34 | 2291 | 2956 | 1550 | 3 pieces | — | — | — |
| CI-EML2-670-35 | 35 | 2358 | 3043 | 1595 | 3 pieces | — | — | — |
| CI-EML2-670-36 | 36 | 2424 | 3130 | 1641 | 3 pieces | — | — | — |
| CI-EML2-670-37 | 37 | 2491 | 3217 | 1686 | 3 pieces | — | — | — |
| CI-EML2-670-38 | 38 | 2557 | 3303 | 1732 | 3 pieces | — | — | — |
| CI-EML2-670-39 | 39 | 2624 | 3390 | 1778 | 3 pieces | — | — | — |
| CI-EML2-670-40 | 40 | 2690 | 3477 | 1823 | 3 pieces | — | — | — |
Branded Paints: Little Greene, Farrow & Ball, Paint & Paper Library, Mylands
Heat output
Output varies with flow temperature. The curve shows watts per section across the usual range of ΔT.
| ΔT (K) | Output per section (W) |
|---|---|
| ΔT15 | 19 |
| ΔT20 | 27.3 |
| ΔT25 | 36.2 |
| ΔT30 | 45.6 |
| ΔT35 | 55.4 |
| ΔT40 | 65.6 |
| ΔT45 | 76.1 |
| ΔT50 | 86.9 |
Specifications
| Ref | Attribute | Value |
|---|---|---|
| A | Height with legs | 670mm |
| B | Pipe centre to floor | 102.3mm |
| C | Max section depth | 170mm |
| D | Interaxis distance | 526mm |
| E | Height without legs | 613mm |
| F | Mid section depth | 150mm |
| G | Pipe centre to wall (Atlas bracket) | 93mm |
| L | Section length | 66.5mm |
| – | Internal volume per section | 1.49L |
| – | Leg section weight | 7.3kg |
| – | Mid section weight | 6.3kg |
| – | Max single-piece delivery size | 14sections |
| – | Output at ΔT30 | 45.6W |
| – | Output at ΔT50 | 86.9W |
φ = Km × ΔTn · Km = 0.619 · n = 1.264
Tested to EN 442 · BSRIA · Test ref: 104331/2
Declaration of Performance: 202209-1085 · CE marked
